| System |
| Main Processor |
Embedded processor |
| Operating System |
Embedded Linux |
| Audio and Video |
| HDCVI Camera Input |
8 Channel, BNC |
| IP Camera Input |
4+2/8+4/16+8 Channel, each channel up to 5MP |
| Audio Input/Output |
4 Channel input,1 Channel output |
| Two-way Talk |
Reuse audio in(channel 1)/out, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Display Split |
4CH: 1/4/6
8CH: 1/4/8/9/16
16CH: 1/4/8/9/16/25 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
H.264+/H.264 |
| Resolution |
1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate |
Main stream: 1080P(1~15fps)/ 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25fps)
Sub steram:D1/CIF/QCIF(1~25fps) |
| Bit Rate |
1Kbps ~ 6144Kbps Per Channel |
| Recording Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Recording Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot,
Buzzer & Screen tips |
| Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering and Diagnosis |
| Alarm Input |
4/8/16 channel |
| Relay Output |
3 channel |
| Playback & Backup |
| Sync Playback |
4CH: 1/4
8CH: 1/4/9
16CH: 1/4/9/16 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device / Network |
| Network |
| Interface |
4CH/8CH: 1 RJ-45 Port (100M)
16CH: 1 RJ-45 Port (1000M) |
| Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.4.1, CGI Conformant |
| Storage |
| Internal HDD |
2 SATA Ports, up to 6TB capacity for each disk |
| HDD Mode |
Single |
| eSATA |
n/a |
| Auxiliary Interface |
| USB Interface |
4/8CH:2 USB Ports (2 USB 2.0)
16CH:2 USB Ports (1 USB 2.0 , 1 USB 3.0) |
| RS485 |
1 port for PTZ Control |
| Electrical |
| Power Supply |
DC12V/4A |
| Power Consumption |
15W(without HDD) |
| Enviromental |
| Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions |
0°C ~ +50°C (+32°F ~ +122°F), 0 ~ 90% RH |
| Enviromental |
| Dimension |
1U, 375mm×285mm×55mm (14.7" x 11.2" x 2.2") |
| Net Weight |
2.35kg (5.2 lb) (without HDD) |
