| System |
| Main Processor |
Embedded processor |
| Operating System |
Embedded Linux |
| Video |
| Input |
32 Channel BNC |
| Standard |
HDCVI:1080P/720P HDCVI Camera
Analogue:PAL
IP:1080P/720P IP Camera |
| Audio |
| Audio Input |
16 channel, BNC |
| Audio Output |
1 channel, BNC |
| Display |
| Interface |
2 HDMI, 1 VGA, 1 TV |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Display Split |
1/4/8/9/16/25/36 |
| Privacy Masking |
4 rectangular zones (each camera) |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Video/Audio Compression |
H.264 / G.711 |
| Record Rate Main Stream: |
1080P(1~12fps)/720P/960H/D1/HD1/2CIF/CIF(1~25fps) |
| Record Rate Extra Stream: |
CIF/QCIF(1~25fps) ,D1 |
| Bit Rate |
48~4096Kb/s |
| Recording Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
| Recording Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
| Video Detection |
Motion Detection, MD Zones: 396(22 x 18), Video Loss & Camera Blank |
| Alarm Input |
16 Channel |
| Alarm Output |
6 Channel |
| Playback & Backup |
| Sync Playback |
1/4/8/16 |
| Search Mode |
Time/Date, MD & Exact search (accurate to second) |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device / eSATA Device / Network |
| Network |
| Interface |
RJ-45 Port (10/100M/1000M) |
| Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Hard Disk |
| Hard Disk |
8 SATA Port, Max 32TB HDD Supported |
| External HDD |
1 eSATA port |
| Auxiliary Interface |
| USB Interface |
4 ports (2 Rear), USB2.0 |
| RS232 |
1 port, For PC communication & Keyboard |
| RS485 |
1 port RS485 for PTZ control, 1 port RS422 for Keyboard |
| Enviromental |
| Power Supply |
AC 100~240 V, 50/60 Hz |
| Power Consumption |
40W(without HDD) |
| Working Temperature |
-10°C - +55°C / 10~90%RH / 86~106kpa |
| Dimension |
2U, 440mm × 460mm × 89mm |
| Weight |
Approx. 6.5Kg (without HDD) |
