| System |
| Main Processor |
Embedded processor |
| Operating System |
Embedded Linux |
| Video |
| Input |
8 Channel, BNC |
| Standard |
HDCVI:1080P/720P HDCVI Camera
Analogue:PAL
IP:8+4 up to 5Mp |
| Audio |
| Audio Input |
4 channel, RCA |
| Audio Output |
1 channel, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Display Split |
1/4/8/9 |
| Privacy Masking |
4 rectangular zones (each camera) |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Video/Audio Compression |
H.264 / G.711 |
| Record Rate |
Main Stream: 1080P(1920 x 1080), 720P(1280 x 720), 960H(960 x 576), D1(704 x 576), CIF(352 x 288) (1~25fps)
Extra Stream: D1/CIF/QCIF(1~25fps) |
| Bit Rate |
1~6144Kb/s |
| Recording Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
| Recording Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips |
| Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blan |
| Alarm Input |
16 Channel |
| Relay Output |
3 Channel |
| Playback & Backup |
| Sync Playback |
1/4/9 |
| Search Mode |
Time/Date, MD & Exact search (accurate to second) |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device / Network |
| Network |
| Interface |
RJ-45 Port (10/100M/1000M) |
| Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Hard Disk |
| Hard Disk |
2 SATA Port, Max 8TB HDD Supported |
| Auxiliary Interface |
| USB Interface |
2 ports (1 Rear USB3.0, 1 Front USB2.0) |
| RS485 |
1 port, For PTZ control |
| Enviromental |
| Power Supply |
DC12V/4A |
| Power Consumption |
15W(without HDD) |
| Working Temperature |
-10°C - +55°C / 10~90%RH / 86~106kpa |
| Dimension |
1U, 375mm x 285mm x 55mm |
| Weight |
Approx. 2.35Kg (without HDD) |
