| Main Processor |
Dual-core embedded processor |
| Operating System |
Embedded Linux |
| Video |
| IP Camera Input |
4 channel |
| Two-way Talk |
1 channel Input, 1 channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
| Display Split |
1/4 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
H.264 / MJPEG |
| Resolution |
5Mp (2560 x 1920) / 3Mp (2048 x 1536) / 1080P (1920 x 1080) / 720P (1280 x 720) / D1 (704 x 576) |
| Record Rate |
80Mbps |
| Bit Rate |
48 ~ 8192kbps |
| Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
| Video Detection |
Motion Detection, MD Zones: 396(22 x 18), Video Loss & Camera Blank |
| Playback & Backup |
| Sync Playback |
1/4 |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device / Network |
| Network |
| Ethernet |
1 x RJ-45 port (10/100M) |
| Wireless Network |
Built-in Wifi module, 2 WiFi Antenna |
| Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Storage |
| Internal HDD |
1 SATA ports, up to 4TB |
| Auxiliary Interface |
| USB |
2 ports (2 Rear), USB2.0 |
| General |
| Power Supply |
DC12V/2A |
| Power Consumption |
10W (without HDD) |
| Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension (W×D×H) |
205mm x 205mm x 45mm |
| Weight |
Approx. 0.5Kg |
