System |
Main Processor |
Embedded processor |
Operating System |
Embedded Linux |
Video |
Max IP Cameras |
16 channel |
Audio |
Audio Input |
n/a |
Audio Output |
n/a |
Display |
Interface |
1 HDMI, 1 VGA |
Display Split |
1/48/9 |
Resolution |
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Compression |
H.264 / MJPEG |
Image Resolution |
1080P(1920 x 1080) - Max 4 Cameras 720P(1280 x 720) - Max 8 Cameras |
Encoding Speed |
200fps @ 720P 100fps @ 1080P |
Bit Rate |
48 ~ 8192kbps |
Recording Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
Recording Interval |
1 to 120 minutes (default 60 mins) pre-record up to 30 seconds, post-record up to 5 minutes |
Video Detection & Alarm |
Trigger Events |
Recording, PTZ movement, Tour, Alarm, Email, FTP, Buzzer & Screen tips |
Motion Detection |
Motion Detection, MD Zones: 396(22 x 18) |
Alarm Input |
n/a |
Relay Output |
n/a |
Playback & Backup |
Sync Playback |
1/4 |
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device / Network |
Network |
Interface |
RJ-45 Port (10/100M/1000M) |
Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Hard Disk |
Hard Disk |
3 SATA Port, Max 9TB HDD Supported |
Storage |
720P: 20~50 G/day for 1ch 1080P: 40~100G/day for 1ch |
Auxiliary Interface |
USB Interface |
2 ports (1 Rear), USB2.0 |
RS485 |
PTZ Control |
Enviromental |
Power Supply |
DC12V/3A |
Power Consumption |
20W(without HDD) |
Working Temperature |
-10°C - +55°C / 10~90%RH / 86~106kpa |
Dimension |
440mm x 345mm x 60mm |
Weight |
Approx. 7.5Kg (without HDD) |
