DS-2CD2055FWD-I Hikvision 5MP 120dB WDR IP Mini Bullet Camera with 30m IR Night Vision & PoE (EasyIP 3.0)
Product ID DS-2CD2055FWD-I-4MM

DS-2CD2055FWD-I Hikvision 5MP 120dB WDR IP Mini Bullet Camera with 30m IR Night Vision & PoE (EasyIP 3.0)

Trade Only Item
In Stock 0
0 reviews | Write a review
3 Year Warranty
IP CCTV
Happy Bday
Happy Bday
Happy Bday

Free Shipping


  • Summary
  • Full Spec
  • Diagram

CCTV Camera Description

The Hikvision DS-2CD2055FWD-I 5MP camera is a fixed lens Ultra HD 5MP(2560 x 1920) mini bullet camera with 120dB Wide Dynamic Range. The camera has built in IR with a range of up to 30m and is housed in an IP67 rated housing suitable for indoor or outdoor use. Some of the great features this camera includes are triple streaming, day/night function and wide dynamic range. The camera can be powered over Ethernet (PoE) for quick and easy installation when used with the plug and play features of our Hikvision NVRs.

This is an amazing value 5MP Camera - that provides 2.5 times the image quality of a 1080P HD camera!

On top of this stunning resolution the DS-2CD2055FWD-I also supports Micro SD card recording, so you can not only record on to your Hikvision NVR but you can have a second short term recording taking place on the camera itself. Perfect for high risk areas or as back up in case the NVR is compromised.

Key features of DS-2CD2055FWD-I

  • Up to 5 megapixel high resolution
  • Max. 2560 x 1920 @25fps
  • 4mm Lens
  • H.265, H.265+, H.264+, H.264
  • 120dB Wide Dynamic Range
  • 3D Digital Noise Reduction
  • IR illuminators: up to 30m
  • DC12V & PoE (802.3af)
  • Support on-board storage, up to 128 GB (Not Included)
  • IP67

Download Hikvision Specification Sheet

Manufacturers Spec Sheet (PDF)

Camera
Image Sensor 1/2.9" Progressive Scan CMOS
Min. Illumination Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR
Shutter Time 1/3s ~ 1/100,000s
Slow Shutter Support
Lens 4mm, horizontal field of view: 63.5°
Angle adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Day & Night IR cut filter with auto switch
Digital noise reduction 3D DNR
WDR 120 dB WDR
Compression Standard
Video compression H.265+ / H.265 / H.264+ / H.264 / MJPEG
Bit rate 32 Kbps ~ 16 Mbps
Triple Streams Yes
Max. Image Resolution 2560 × 1920
Frame rate 50Hz: 20 fps (2560 × 1920), 25 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 ×720)
Sub Stream 50Hz: 25fps (640 × 360, 352 × 288)
Third Stream 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
Image Enhancement BLC/3D DNR
Image settings Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
ROI Support 1 fixed region for each stream, and face dynamic tracking
Day/Night Switch Auto / Scheduled
Network
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
General Function One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility ONVIF (Profile S, Profile G), ISAPI
Interface
Communication interface 1 RJ45 10M / 100M Ethernet interface
On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Smart Feature-set
Behavior Analysis Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
Line Crossing Detection Cross a pre-defined virtual line
Intrusion Detection Enter and loiter in a pre-defined virtual region
Unattended Baggage Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal Objects removed from the pre-defined region, such as the exhibits on display
Recognition Face Detection
General
Operating Conditions -30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption Max. 6W
Weather Proof Ratings IP67
Impact Protection n/a
IR Range up to 30m
Dimensions Camera: Φ70 × 155.03 mm
Package: 216 × 121 × 118
Weight Approx. 410g

dvr dimensions
