Camera |
Image Sensor |
1/2.9" Progressive Scan CMOS |
Min. Illumination |
Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR |
Shutter Time |
1/3s ~ 1/100,000s |
Slow Shutter |
Support |
Auto Iris |
No |
Lens |
2.8 mm, horizontal field of view: 97° |
Angle adjustment |
Pan: -30° to +30°, tilt: 0° to 75°, rotate: 0° to 360° |
Day & Night |
IR cut filter with auto switch |
Digital noise reduction |
3D DNR |
WDR |
120 dB WDR |
Compression Standard |
Video compression |
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264 |
Bit rate |
256 Kbps ~ 16 Mbps |
Audio Compression |
G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM |
Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32 192Kbps(MP2L2) |
Triple Streams |
Yes |
Image |
Max. Image Resolution |
3072 x 2048 |
Frame rate |
50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) |
Image Enhancement |
BLC/ 3D DNR/ HLC |
Image settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
Day/Night Switch |
Auto/Schedule/Day/Night/Triggered by Alarm In (-S) |
Network |
Network Storage |
Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR |
Alarm Trigger |
Motion detection, tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
General Function |
One-key reset, Anti-Flicker, three streams, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering |
System Compatibility |
ONVIF (Profile S, Profile G), ISAPI |
Interface |
Audio (-S model) |
2 Inputs: line in or mic in (built in microphone), 1 output: line out, mono sound, terminal block |
Alarm (-S model) |
1 Input: Alarm in, 1 Output: Alarm out (max. 12 VDC, 30 mA), terminal block |
Communication interface |
1 RJ45 10M / 100M Ethernet interface |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Reset Button |
Yes |
SVC |
H.265 encoding and H.264 encoding support |
Audio (-S Model) |
Environment Noise Filtering |
Yes |
Audio Sampling Rate |
16 kHz, 32kHz, 44.1kHz, 48kHz |
Smart Feature-set |
Behavior Analysis |
Line crossing detection, intrusion detection |
Face Detection |
Yes |
Region of Interest |
Support 1 fixed region for main stream and sub-stream |
General |
Operating Conditions |
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
Power Consumption |
12 VDC, 0.7 A, max. 8.5 W, Φ 5.5mm coaxial plug power
PoE (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 10 W |
Weather Proof Ratings |
IP66 |
Impact Protection |
IK08 |
IR Range |
up to 10m |
Dimensions |
Camera: Φ110 mm × 56.4 mm |
Weight |
Approx. 400g |
