| Camera |
| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Time |
1/3s ~ 1/100,000s |
| Slow Shutter |
Support |
| Angle adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Day & Night |
IR cut filter with auto switch |
| Digital noise reduction |
3D DNR |
| WDR |
120 dB WDR |
| Lens |
| Lens |
2.8 to 12 mm |
| FOV |
Horizontal field of view: 115° to 35°
Vertical field of view: 60° to 19°
Diagonal field of view: 146° to 38.5° |
| Lens mount |
φ14 |
| Focus |
Motorized VF lens |
| Compression Standard |
| Video compression |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Bit rate |
32 Kbps ~ 16 Mbps |
| Triple Streams |
Yes |
| Audio compression |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit rate |
32 to 128kbps |
| Image |
| Max. Image Resolution |
3840 × 2160 |
| Frame rate |
50Hz: 20 fps (3840 × 2160), 25 fps (2944 × 1656, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 360, 352 × 288) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) |
| Image Enhancement |
BLC/3D DNR |
| Image settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Regional Cropping |
Support |
| ROI |
Support 1 fixed region for each stream, and face dynamic tracking |
| Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
| Network |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function |
One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| Communication interface |
1 RJ45 10M / 100M Ethernet interface |
| Alarm |
1 input, 1 output (max. 12 VDC, 30 mA) |
| Video Output |
1Vp-p Composite Output (75 Ω, BNC) |
| Reset Button |
Yes |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Audio |
| Environment Noise Filtering |
Support |
| Smart Feature-set |
| Behavior Analysis |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Line Crossing Detection |
Cross a pre-defined virtual line |
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region |
| Unattended Baggage |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal |
Objects removed from the pre-defined region, such as the exhibits on display |
| Face Detection |
Support |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption |
Max. 12.9W |
| Weather Proof Ratings |
IP67 |
| Impact Protection |
IK10 |
| IR Range |
up to 30m |
| Dimensions |
Camera: Φ153.4 × 133.1 mm |
| Weight |
Approx. 1287g |
