| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01lux @(F1.2, AGC ON), 0.018lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Time |
1/3s ~ 1/100,000s |
| Lens |
1.6mm, F1.6 Angle of view: 186°(horizontal), 106°(vertical) |
| Day & Night |
ICR |
| Compression Standard |
| Video compression |
H.264 / MJPEG |
| H.264 code profile |
Baseline Profile / Main Profile |
| Bit rate |
32 Kbps ~ 8 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit rate |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image |
| Max. Image Resolution |
2560 × 1440 |
| Frame rate |
50Hz: 12.5fps(2560 × 1440), 25fps(1920 × 1080, 1280 × 720) |
| Image Enhancement |
BLC/3D DNR/ROI/Defog |
| Image settings |
Saturation, Brightness, Contrast , Hue, Sharpness, AGC, White Balance |
| Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
| Alarm trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Interoperability |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Security |
User Authentication, Watermark, IP address filtering, Anonymous access |
| Interface |
| Audio |
Internal Microphone and Speaker |
| Communication interface |
1 RJ45 10 M / 100 M Ethernet port |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 64 GB |
| Reset Button |
Yes |
| Wi-Fi |
| Wi-Fi standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency range |
2.4 GHz ~ 2.4835 GHz |
| Channel bandwidth |
Support 20/40 MHz |
| Modulation Mode |
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Power |
11b: 17±1.5dBm @ 11Mbps
11g: 14±1.5dBm @ 54Mbps
11n: 12.5±1.5dBm |
| Receive Sensitivity |
11b: -90dBm @ 11Mbps (Typical)
11g: -75dBm @ 54Mpbs (Typical)
11n: -74dBm (Typical) |
| Transmission rate |
11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Wireless Range |
50m(depend on environment) |
| General |
| Operating Conditions |
-10 °C ~ 40 °C (14°F ~ 104 °F) humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 10% , PoE (802.3af) |
| Power Consumption |
Max. 5.55W |
| Weather Proof Ratings |
n/a |
| IR Range |
up to 8m |
| Dimensions |
ø119.9 x 41.2 (ø4.72” × 1.62”) |
| Weight |
Approx. 600g |
