| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
| Shutter Time |
1/3s ~ 1/10,000s |
| Lens |
4mm / 2.8mm @ F2.0, angle of view: 106°(2.8mm), 83°(4mm), 55.4°(6mm) |
| Angle adjustment |
Pan: -30° ~ 30°, Tilt: 0 ~ 75°, Rotation: 0 ~ 360° |
| Day & Night |
ICR |
| Digital noise reduction |
3D DNR |
| WDR |
120 dB WDR |
| Compression Standard |
| Video compression |
H.264 / MJPEG / H.264+ |
| H.264 codec profile |
Main profile |
| Video bit rate |
32Kbps~16Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Dual Stream |
Yes |
| Image |
| Max. Image Resolution |
2688 × 1520 |
| Frame rate |
50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) |
| Image settings |
Rotate Mode, Saturation, brightness, contrast, sharpeness adjustable through client software or web browser |
| BLC |
Yes, zone configurable |
| ROI |
Support |
| Network |
| Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security |
One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| Audio |
1-ch 3.5 mm audio in (Mic in/Line in)/out interface |
| Communication interface |
1 RJ45 10 M / 100 M Ethernet interface |
| Alarm |
1x alarm I/O |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button |
Yes |
| General |
| Operating Conditions |
-30°C ~ 60°C (-22°F ~ 140°F) humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 10% , PoE (802.3af) |
| Power Consumption |
Max. 5W |
| Impact protection |
up to IK08 |
| Weather Proof Ratings |
IP66 |
| IR Range |
10m |
| Dimensions |
99.3 × 96.7 × 52.8 mm |
| Weight |
Approx. 600g |
