| Camera |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.05lux @(F1.2, AGC ON), 0.3lux @(F2.0, AGC ON), 0 lux with IR |
| Shutter Time |
1/25s ~ 1/100,000s |
| Lens |
1.27mm, F2.8 - Angle of view: 180°(wall mount), 360°(ceiling mount) |
| Day & Night |
ICR |
| WDR |
Digital WDR |
| Digital noise reduction |
3D DNR |
| Compression Standard |
| Video compression |
H.264 / MJPEG |
| Bit rate |
32 Kbps ~ 16 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
| Dual Stream |
Yes |
| Image |
| Max. Image Resolution |
3072 x 2048 |
| Frame rate |
Mode1
50Hz: 1×fisheye (1280×1280, 12.5fps), 1×panoramic (2048×1536, 12.5fps), 3×PTZ (1024×768, 12.5fps)
Mode2
50Hz: 1×fisheye (3072×2048/2048×2048, 25fps) or 4×PTZ (1024×768, 25fps)
Mode3
50Hz: 1×Fisheye(2048×2048, 12.5fps; 1024×1024, 25fps) + 1×Fisheye(720×720, 12.5fps) +
3×PTZ(1024×768, 12.5fps)
Mode4
50Hz:1×Panorama(2048×1536(ceiling or table)/1920×1080(ceiling or table) /2048×1536
(wall mount)/2048×768(wall mount), 25fps) + 1×Panorama(704×576, 25fps) |
| Image settings |
Saturation, brightness, contrast adjustable through client software or web browser |
| ROI |
Support |
| Network |
| Network Storage |
NAS (Support NFS,SMB/CIFS) |
| Alarm trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Interoperability |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Security |
User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
| Interface |
| Audio |
Internal Microphone and Speaker |
| Communication interface |
1 RJ45 10 M / 100 M Ethernet port |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 64 GB |
| Reset Button |
Yes |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 10% , PoE (802.3af) |
| Power Consumption |
Max. 12W |
| Impact Protection |
IEC60068-2-75Eh, 50J; EN50102, IK10 |
| Weather Proof Ratings |
IP66 |
| IR Range |
up to 15m |
| Dimensions |
164 x 152.8 x 43.8mm (6.46” x 6.02” x 1.72”) |
| Weight |
Approx. 1400g |
