| Video/Audio Input |
| IP video input |
64CH |
| Incoming bandwidth |
320Mbps |
| Outgoing bandwidth |
256Mbps |
Incoming bandwidth
(RAID mode) |
200Mbps |
Outgoing bandwidth
(RAID mode) |
200Mbps |
| HDMI 1 output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA 1 output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA 2 output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video output mode |
HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output |
| Audio output |
2-ch, RCA (Linear, 1kΩ) |
| Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| Decoding |
| Recording resolution |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
*: After ultra HD resolution mode is enabled, the NVR supports up to 4-ch 32 MP/24 MP IP video inputs. |
| Capability |
1-ch@32 MP (30 fps)/2-ch@12 MP (20fps)/4-ch@8 MP (25fps)/8-ch@4 MP (30fps)/16-ch@1080p (30fps) |
| Network |
| Remote connection |
128 |
| Network protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
| Network interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Network mode |
Net Fault-Tolerance, Multi-address |
| RAID |
| RAID Type |
RAID0, RAID1, RAID5, RAID6, and RAID10 (at least 4 TB for each HDD) |
| Auxiliary interface |
| SATA |
8 SATA interfaces supporting hot-plug |
| Capacity |
Up to 10TB capacity for each HDD |
| USB interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm Input |
16-ch |
| Alarm Output |
4-ch |
| PoE |
| Interface |
n/a |
| General |
| Power supply |
100 to 240 VAC |
| Consumption |
Max 30W (without hard disk and POE) |
| Working temperature |
-10 °C ~ +55 °C |
| Working humidity |
10% ~ 90% |
| Chassis |
3U chassis |
| Dimensions (W x D x H) |
445 × 465 × 92 mm |
| Weight |
Approx. 10Kg (without hdd) |
