| Camera |
    | Image Sensor | 1/3" Progressive Scan CMOS |
    | Max. Resolution | 2560 x 1440 |
    | Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light |
    | Shutter Time | 1/3 s to 1/100,000 s |
    | Day & Night | IR cut filter |
    | Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360° |
| Lens |
|---|
    | Lens Type | Fixed focal lens, 2.8mm |
    | Focal Length & FOV | 2.8 mm, horizontal FOV 96°, vertical FOV 52°, diagonal FOV 114° |
    | Lens Mount | M12 |
    | Iris Type | Fixed |
    | Aperture | F1.0 |
    | DORI |
    | DORI | 2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m |
    | Illuminator |
    | Supplement Light Type | IR, White Light |
    | Supplement Light Range | Up to 30 m |
    | Smart Supplement Light | Yes |
    | IR Wavelength | 850nm |
    | Video |
    | Main Stream | 50 Hz: 20 fps (2560 × 1440)
 25 fps (1920 × 1080, 1280 × 720)
 60 Hz:
 20 fps (2560 × 1440)
 24 fps (1920 × 1080, 1280 × 720)
 |
    | Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
 |
    | Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
 |
    | Video Bit Rate | 32Kbps to 8Mbps |
    | H.264 Type | Baseline Profile,Main Profile,High Profile |
    | H.265 Type | Main Profile |
    | Bit Rate Control | CBR,VBR |
    | Region Of Interest (ROI) | 1 fixed region(s) for main stream |
    | Audio |
    | Audio Type | Mono sound |
    | Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
    | Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64Kbps (AAC-LC) |
    | Audio Sampling Rate | 8 kHz/16 kHz |
    | Environment Noise Filtering | Yes |
    | Network |
    | Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP |
    | Simultaneous Live View | Up to 6 channels |
    | API | Open Network Video Interface (Profile S, Profile T), ISAPI, SDK |
    | User/Host | Up to 32 users 3 user levels: administrator, operator, and user
 |
    | Security | Password protection, complicated password, watermark, basic and digest
authentication for HTTP, WSSE and digest authentication for Open Network Video
Interface, security audit log, host authentication (MAC address) |
    | Client | iVMS-4200, HiLookVision |
    | Web Browser | Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
 |
    | Image |
    | Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
    | Day/Night Switch | Day, Night, Auto, Schedule |
    | Wide Dynamic Range (WDR) | 120 dB |
    | SNR | ≥ 52 dB |
    | Image Enhancement | BLC,HLC,3D DNR |
    | Privacy Mask | 4 programmable polygon privacy masks |
    | Interface |
    | Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
    | Built in microphone | Yes |
    | Event |
    | Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
    | Linkage | Upload to FTP, notify surveillance center, send email, trigger capture |
    | General |
    | Power | 12 VDC ± 25%, 0.5 A, max. 6.0 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W
 |
    | Material | Metal & Plastic |
    | Dimension | Ø112 mm × 82 mm (Ø4.41" × 3.23") |
    | Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.55") |
    | Weight | Approx. 370 g (0.8 lb.) |
    | With Package Weight | Approx. 610 g (1.3 lb.) |
    | Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
    | Startup And Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
    | Language | English, Ukranian |
    | General Function | Heartbeat, anti-banding, mirror, password protection, password reset by email |
    | Approval |
    | EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
 RCM: AS/NZS CISPR 32: 2015,
 IC: ICES-003: Issue 7
 |
    | Safety | CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
 |
    | Environment | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU,
 Reach: Regulation (EC) No 1907/2006
 |
    | Protection | IP67: IEC 60529-2013 |
