| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time |
1/3s ~ 1/100,000s |
| Lens |
2.8mm - horizontal field of view 108° |
| Lens Mount |
M12 |
| Day & Night |
ICR |
| IR Range |
up to 30m |
| Adjustment Range: (Manual) |
Pan:0° - 360°, Tilt: 0° - 75°, Rotation: 0° - 360° |
| Digital noise reduction |
3D DNR |
| WDR |
120dB |
| Compression Standard |
| Video compression |
H.265+/H.265/H.264+/H.264 |
| H.264 code profile |
Baseline Profile/Main Profile/High Profile |
| Bit rate |
32 Kbps ~ 16 Mbps |
| Smart Feature-set |
| Region of Interest |
1 fixed region for main stream and sub-stream |
| Audio |
| Built in Mic |
Yes |
| Image |
| Max. Image Resolution |
3840 x 2160 |
| Main Stream |
50Hz: 12.5 fps (3840 × 2160), 20 fps (2592 × 1944), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image settings |
Mirror, rotate, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Network |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, security audit log, TLS 1.2, host authentication (MAC address) |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, 802.1x, SMTP |
| Interface |
| Ethernet interface |
1 RJ45 10 M / 100 M Self adaptive Ethernet port |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25% , PoE (802.3af, class 3) |
| Power Consumption |
Max. 5W |
| Ingress Protection |
IP67 |
| Material |
Metal |
| Dimensions |
Ø110 mm × 95.2 mm |
