HL-NVR-104MH-K-4P HiLook by Hikvision 4 Channel H.265 12MP "Pro Series" NVR with 4 PoE Ports

Product ID HL-NVR-104MH-K-4P

£188.00

HL-NVR-104MH-K-4P HiLook by Hikvision 4 Channel H.265 12MP "Pro Series" NVR with 4 PoE Ports

Up Grade HDD

Recording times (in Days) with 2000GB HDD

Cameras Connected	2MP (1080P HD) resolution		5MP resolution		8MP resolution
Frame rate (per channel)	15fps	25fps	15fps	25fps	15fps	25fps
2 cameras	73	44	32	19	19	11
4 cameras	36	22	16	9	9	5
8 cameras	18	11	8	4	4	2
16 cameras	9	5	4	2	2	1

The above is based on a 2000Gb HDD in H.265, other hard drives will record for different periods of time for example a 4000Gb would record for double the above times and a 1000Gb would record for half the above times.

Recording times are only a guide and will vary dependent on the actually scene being recorded.

£188.00

Quantity

Free Shipping

Summary
Full Spec
Dimensions

About the HL-NVR-104MH-K-4P

HiLook Pro Series HL-NVR-104MH-K-4P – Smart, Simple & Secure 4-Channel Network Video Recorder

The HL-NVR-104MH-K-4P is a HiLook by Hikvision Pro Series 4 channel NVR with 4 built in PoE ports.

Each camera plugs straight into the back with one network cable for power and video, which makes it a simple choice for a home, shop or small office.

It records up to 12MP per channel, and Motion Detection 2.0 tells people and vehicles apart from other movement. It can also recognise faces.

It takes one hard drive of up to 16TB (not included) and has a 4K HDMI output. You can watch live, play back footage and get alerts on your phone with the free HiLookVision app.

HL-NVR-104MH-K-4P Key Features

4 PoE ports built-in for direct camera connection
Up to 12MP recording resolution supported
Motion Detection 2.0 – human and vehicle classification
Facial detection and recognition with up to 20,000 face images
H.265+/H.265/H.264+/H.264 video compression supported
HDMI output up to 4K and VGA up to 1080p
1 SATA interface supports up to 16TB HDD
Simultaneous HDMI/VGA output and 4-ch playback
Supports up to 128 remote access connections
Compact and efficient 1U desktop design

Download

Manufacturers Spec Sheet (PDF)

Specification

Video and Audio
IP video input	4-ch
Incoming bandwidth	40Mbps
Outgoing bandwidth	80Mbps
HDMI output	1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA output	1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Audio output	1-ch, RCA (Linear, 1 KΩ)
Two-way audio input	1-ch, RCA (2.0 Vp-p, 1 KΩ)
Decoding
Decoding format	H.265/H.265+/H.264+/H.264
Recording resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback	4-ch
Decoding capability	AI on: 1-ch@12MP (30fps) / 2-ch@8MP (30fps) / 4-ch@4MP (30fps) / 8-ch@1080p (30fps) AI off: 1-ch@12MP (30fps) / 2-ch@8MP (30fps) / 4-ch@4MP (30fps) / 8-ch@1080p (30fps)
Network
Remote connection	128
Network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
PoE
PoE interface	4 × RJ-45 10/100 Mbps self-adaptive Ethernet interface
Max. Power	50 W
Supported standard	IEEE 802.3 af/at
Auxiliary Interface
SATA	1 SATA interface
Capacity	Up to 16 TB capacity for each HDD
USB interface	Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
General
Power supply	48 VDC, 1.35 A
Consumption	≤ 10 W (without HDD, and PoE off)
Working temperature	-10 °C ~ +55 °C
Working humidity	10% ~ 90%
Dimensions (W × D × H)	320 mm × 240 mm × 48 mm
Weight	Approx. 1 kg (without HDD)
