DS-2CD2F22FWD-IS Hikvision 1080P HD WDR Indoor Pan & Tilt IP Dome with 10m IR / PoE / Audio I/O (6mm Lens/1Yr)
Product ID DS-2CD2F22FWD-IS

DS-2CD2F22FWD-IS Hikvision 1080P HD WDR Indoor Pan & Tilt IP Dome with 10m IR / PoE / Audio I/O (6mm Lens/1Yr)

Trade Only Item
In Stock 0
0 reviews | Write a review
1 Year Warranty
IP CCTV
Happy Bday
Happy Bday
Happy Bday

Free Shipping


  • Summary
  • Full Spec
  • Diagram

Description

The Hikvision DS-2CD2F22FWD-IS is a 2 megapixel (1920 x 1080) Pan & Tilt camera and has a 6mm fixed lens which provides an angle view of 53°. Some of the great features this camera includes are day/night function and digital wide dynamic range.

The camera can be used Indoors only, but can see in total darkness up to a maximum of 10 Metres.

This model has audio inputs and outputs - so you can connect your own microphones and hear what is happening around the camera.

Key Features

  • Up to 2 megapixel high resolution
  • 6mm lens (53° Angle of View)
  • Full HD 1080P Video
  • Dual stream
  • 120dB Wide Dynamic Range
  • Pan & tilt rotation
  • Support on-board storage, up to 128GB
  • DC12V & PoE
  • Support H.264+
  • Up to 10m IR range
  • Audio/Alarm IO

Download

Manufacturers Spec Sheet (PDF)

Sample Footage

Please make sure you select 1080P HD resolution when viewing this footage.

The above footage shows the quality image provided by this camera both day and night. To get an idea of distance the orange door in the video is approx 5 Metres from the camera.

Camera
Image Sensor 1/2.8" Progressive Scan CMOS
Min. Illumination 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter time 1/3 s to 1/10,000 s
Lens 6mm @ F2.0 angle of view: 53.9°
Lens Mount M12
Adjustment Range Pan: -90° ~ 90°, Tilt: 0° ~ 75°
Day & Night IR cut filter with auto switch
WDR 120dB
Digital noise reduction 3D DNR
Compression Standard
Video compression H.264 / MJPEG / H.264+
H.264 codec profile Main profile
Bit rate 32 Kbps ~ 16 Mbps
Dual Stream Yes
Max. Image Resolution 1920 x 1080
Frame rate 50Hz: 25fps(1920×1080), 25fps(1280×720)
Image settings Rotate Mode, Saturation, brightness, contrast, sharpeness adjustable through client software or web browser
BLC Yes, zone configurable
ROI Support
Network
Network Storage NAS (Support NFS,SMB/CIFS), ANR
Alarm Trigger Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access
System Compatibility ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Audio 1-ch 3.5 mm audio in (Mic in/Line in)/out interface
Communication interface 1 RJ45 10 M / 100 M Ethernet interface
Alarm 1x alarm I/O
On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button Yes
General
Operating Conditions -10 °C ~ 40 °C (14°F ~ 104 °F) humidity 90% or less (non-condensing)
Power Supply 12 VDC ± 10% , PoE (802.3af Class3)
Power Consumption Max. 5W (Max. 7 W with IR cut filter on, max. 9W with pan & tilt rotation)
Weather Proof Ratings n/a
IR Range up to 10m
Dimensions Φ119.93 × 87.08mm
Weight Approx. 500g

dimensions
