| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Effective Pixels |
1920(H) x 1080(V) |
| Min. Illumination |
Color: 0.05 Lux @ (F1.6, AGC ON)
B/W: 0.01 Lux @ (F1.6, AGC ON)
0 Lux with IR |
| White Balance |
Auto / Manual / ATW / Indoor / Outdoor / Daylight lamp / Sodium lamp |
| AGC |
Auto / Manual |
| BLC |
On / Off |
| HLC |
Support |
| WDR |
Support |
| Shutter Time |
1-1 to 1/30,000s |
| Day & Night |
ICR |
| Digital Zoom |
16X |
| Privacy Masking |
8 privacy masks programmable |
| Auto Focus |
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length |
4.7-94.0mm, 20x |
| Zoom Speed |
Approx 2.7s |
| Angle of View |
61.4° to 2.9° (wide-tele) |
| Minimum Working Distance |
10 - 1500mm(Wide-Tele) |
| Aperture Range |
F1.6 - F3.5 |
| Pan & Tilt |
| Pan Range |
360° continuous |
| Pan Speed |
Configurable, from 0.1°/s to 300°/s
Preset Speed: 350°/s |
| Tilt Range |
-5° - 90° (Auto Flip ) |
| Tilt Speed |
Configurable, from 0.1°/s to 160°/s
Preset Speed: 200°/s |
| Proportional Zoom |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset |
300 |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Pattern |
4 pattern scans, record time over 10 minutes for each scan |
| Power loss recovery |
Support |
| Park Action |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display |
ON / OFF |
| Freeze Frame |
Support |
| Infrared |
| IR irradiation distance |
50m |
| IR irradiation angle |
Adjustable by zoom |
| Alarm |
| Alarm Input |
2 |
| Alarm Output |
2 |
| Alarm Actions |
Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Input & Output |
| Audio Input |
Audio input (LINE input), 2-2.4Vp-p; output impedance: 1KΩ, ±10% |
| Audio Output |
1 Audio output interface
Line level, impedance: 600Ω |
| Network |
| Ethernet |
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution |
1920 x 1080 |
| Sub Stream |
50Hz: 25fps(704×576, 640x480,352×288) |
| Third Stream |
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) |
| Image Compression |
H.264/MJPEG |
| Audio Compression |
G.711ulaw / G.711alaw / G.726 / MP2L2 / G.722 |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour |
| No. of Simultaneous Users |
Up to 20 users |
| Three-Stream |
Support |
| Mini SD Card |
Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording |
| User / Host Level |
Up to 32 users
3 Levels: Administrator, Operator and User |
| Security |
User authentication (ID and PW)
host authentication (MAC address)
IP address filtering |
| EZVIZ |
Support |
| Client GUI |
| Client |
Support iVMS-4200 |
| Web Browser |
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 + |
| General |
| Menu Language |
English |
| Power Supply |
12 VDC & POE (802.3at,class4) |
| Power Consumption |
Max.: 18W (IR light 5W Max.) |
| Working Temperature/Humidity |
-30 °C ~ 65 °C (-22°F ~ 149 °F)90% or less |
| Protection Level |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting |
Variable installation methods optional, including ceiling mounting (default), in-ceiling mounting, junction box installation and wall mounting |
| Dimensions |
Φ169.39mm x 161mm |
| Weight (approx.) |
2.45kg |
| Mount Option |
DS-1605ZJ Wall Mount Bracket, DS-1671ZJ-SD11 In-ceiling Mount Bracket, DS-1280ZJ-SD11 Junction Box, DS-1691ZJ-(M)(L) Pendant Mount Bracket |
