| Camera |
|---|
| Image Sensor | 8 MP CMOS |
| Signal System | PAL/NTSC |
| Resolution | 3840 (H) × 2160 (V) |
| Frame Rate | TVI: 8 MP @ 12.5 fps/15 fps, 3K @ 20 fps, 1080P @ 25 fps/30 fps |
| Min. Illumination | 0.0005 Lux@(F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/12.5 s to 1/50,000 s; NTSC: 1/15 s to 1/50,000 s |
| Lens | 2.8 mm, 3.6 mm fixed focal lens |
| Field of View | 2.8 mm, horizontal FOV: 110°, vertical FOV: 59°, diagonal FOV: 131° |
| Lens Mount | M16 |
| Light Alarm | Solid Light Alarm (White Light) |
| Day & Night | Color |
| WDR (Wide Dynamic Range) | ≥130 dB |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| Image |
|---|
| White Light | Auto/Off |
| Image Mode | STD/HIGH-SAT/HIGHLIGHT |
| AGC | Yes |
| Day/Night Mode | Color |
| White Balance | Auto/Manual |
| AE (Auto Exposure) Mode | WDR, BLC, HLC, Global, HLS |
| Privacy Mask | 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Noise Reduction | 3D DNR/2D DNR |
| Language | English |
| Function | Brightness, Contrast, Mirror, Sharpness, Anti-Banding, Smart Light |
| Interface |
|---|
| Video Output | 1 HD analog output |
| General |
|---|
| Operating Conditions | -40°C to 50°C (-40°F to 130°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%/PoC.at
*You are recommended to use one power adapter for one camera, and use 2-pin
power supply for long-distance power supply. |
| Consumption | Max. 5.1 W |
| Protection Level | IP67 |
| Material | Main body: Metal, Enclosure: Plastic |
| White Light Range | Up to 40 m |
| Communication | HIKVISION-C |
| Dimension | 194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93") |
| Weight | Approx. 350 g (0.77 lb.) |
