Hikvision DS-7604NXI K1/4P(D) 4 Channel AcuSense NVR with 4 PoE Ports

Product ID DS-7604NXI-K1-4P

Trade Only Item

Hikvision DS-7604NXI K1/4P(D) 4 Channel AcuSense NVR with 4 PoE Ports

Up Grade HDD

Recording times (in Days) with 2000GB HDD

Cameras Connected	2MP (1080P HD) resolution		5MP resolution		8MP resolution
Frame rate (per channel)	15fps	25fps	15fps	25fps	15fps	25fps
2 cameras	73	44	32	19	19	11
4 cameras	36	22	16	9	9	5
8 cameras	18	11	8	4	4	2
16 cameras	9	5	4	2	2	1

The above is based on a 2000Gb HDD in H.265, other hard drives will record for different periods of time for example a 4000Gb would record for double the above times and a 1000Gb would record for half the above times.

Recording times are only a guide and will vary dependent on the actually scene being recorded.

Trade Only Item

Quantity

Free Shipping

Summary
Full Spec
Dimensions

About the DS-7604NXI-K1-4P

The DS-7604NXI-K1/4P is a Hikvision 4 channel AcuSense NVR with 4 built in PoE ports.

Each camera plugs straight in with one network cable. AcuSense tells people and vehicles apart from other movement, even on cameras that don't have it built in, and it can recognise faces.

It records up to 12MP per channel, takes one hard drive of up to 10TB (not included) and has a 4K HDMI output. It works with the free Hik-Connect app.

DS-7604NXI-K1-4P Key Features

4-channel IP video input, supports cameras up to 12MP resolution
4 built-in plug-and-play PoE ports (10/100 Mbps, independent interfaces)
AcuSense deep learning analytics, Motion Detection 2.0 all channels, facial recognition, perimeter protection
H.265+, H.265, H.264+, H.264 video compression, H.265+ reduces storage by up to -75%
40 Mbps incoming, 80 Mbps outgoing bandwidth
4K HDMI output (3840 x 2160/30Hz) and VGA output, simultaneous
Decoding: 1-ch at 12MP, 3-ch at 4MP, 6-ch at 1080p (AI on)
1 SATA interface, supports 1 HDD up to 10TB
4-channel synchronous playback
Smart search and smart playback by target type
TLS stream encryption for secure remote access
2x USB 2.0 ports
1x RJ-45 Gigabit network interface
Compact 1U housing, 320 x 240 x 48mm

Download

Manufacturers Spec Sheet (PDF)

Video and Audio
IP Video Input	4-ch
Max Recording Resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/720p and below
Two-Way Audio Input	1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output	1-ch, RCA (Linear, 1 KΩ)
Network
Incoming Bandwidth	40 Mbps
Outgoing Bandwidth	80 Mbps
Network Interface	1x RJ-45 10/100/1000 Mbps self-adaptive Ethernet
Video Output
HDMI Output	1-ch, 4K (3840x2160)/30Hz, 2K (2560x1440)/60Hz, 1920x1080/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output	1-ch, 1920x1080/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode	HDMI and VGA simultaneous output
Decoding
Decoding Format	H.265+, H.265, H.264+, H.264
Decoding Capability (AI on)	1-ch@12MP/1-ch@8MP/3-ch@4MP/6-ch@1080p (all at 30fps)
Decoding Capability (AI off)	1-ch@12MP/2-ch@8MP/4-ch@4MP/8-ch@1080p (all at 30fps)
Synchronous Playback	4-ch
AcuSense Analytics
Motion Detection 2.0	All channels
Facial Recognition	1-ch for video stream, or 2-ch for face picture comparison
Perimeter Protection	1-ch, 4MP, human and vehicle classification
Smart Search / Playback	Yes, by target type
Storage
SATA Interfaces	1, supports 1 HDD up to 10TB
External Interface
PoE Interfaces	4 independent 10/100 Mbps PoE Ethernet interfaces
USB	2x USB 2.0
General
Power Supply	100 to 240 VAC
Power Consumption	Max 15W (without HDD and PoE)
Dimensions	320 x 240 x 48mm
Form Factor	1U compact desktop
