DS-7208HTHI-K2 Hikvision 8 Channel 8MP (4K) HD-TVI Hybrid DVR with CVBS (Turbo4.0)
Product Code DS-7208HTHI-K2

DS-7208HTHI-K2 Hikvision 8 Channel 8MP (4K) HD-TVI Hybrid DVR with CVBS (Turbo4.0)

Login for Price
0 reviews | Write a review
3 Year Warranty
HD-TVI CCTV

  • Summary
  • Full Spec
  • Diagram

Hikvision, a leading provider of CCTV recorders, cameras and accessories have continued their trend of producing high quality CCTV recorders with the Hikvision DS-7208HTHI-K2. This eight channel, Turbo HD TV CCTV DVR supports 8 cameras of up to 8mp resolution as well as four additional IP cameras. It comes with the usual great features you would expect from a Hikvision product such as plug and play support, latency free 1080p video (dependant on coax cable length) and video encoding that saves space on your hard drive. Connecting your home CCTV system has never been so easy and with Hik-Connect you can experience mobile phone viewing and connection to the internet with very little technical knowledge.

Key CCTV Recorder Features

  • H.265+/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
  • Self-adaptive HD-TVI / HD-CVI / AHD / CVBS signal input
  • Connectable to 2 x H.265+/H.265/H.264+/H.264 IP cameras
  • Up to 8 MP resolution for recording
  • VGA output at up to 1920 x 1080P resolution
  • HDMI output at up to 4K (3840 × 2160) resolution
  • Long transmission distance over coax cable
  • Support up to 8-ch synchronous
  • Internet & Smart Phone compatible

Download Hikvision DS-7204HTHI-K1 Specification Sheets

Manufacturers Spec Sheet (PDF)

Video / Audio Input
Audio Input 4ch
Video compression H.265+/H.265/H.264+/H.264
Analog and HD-TVI Video Input 8CH; BNC interface (1.0Vp-p, 75 Ω)
Supported Camera Types Support HDTVI input: 8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
Support AHD input: 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVI input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVBS input: PAL
Video Input Interface BNC (1.0 Vp-p, 75Ω)
Audio compression G.711u
Audio input 4ch RCA (2.0 Vp-p, 1 KΩ)
Video / Audio Output
CVBS output 1-ch, BNC(1.0Vp-p,75Ω), resolution:PAL:704x576
VGA output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI output 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Encoding resolution 8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate Main stream:
8 MP@12fps, 5 MP@20fps, 3 MP@18fps
4MP/1080p/720p/WD1/4CIF/VGA/CIF@25fps
Sub-stream:
WD1/4CIF/CIF@25fps
Video bit rate 32 Kbps - 16 Mbps
Stream type Video, Video & Audio
Audio output 1-ch, RCA (Linear, 1KΩ)
Audio bit rate 64 Kbps
Dual-stream Support
Synchronous playback 8ch
Network Management
Remote Connections 64
Network Protocols TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Hard Disk
SATA 2 SATA interface
Capacity Up to 8 TB capacity for each disk
External Interface
Network interface 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
USB interface Front panel: 1 × USB 2.0, Rear panel: 1 × USB 3.0
Serial interface RS-485 half-duplex
Alarm in/out 8/4
General
Power supply 12v DC
Consumption Max 20W
Working temperature -10 °C ~ +55 °C
Working humidity 10% ~ 90%
Dimensions (W x H x D) 380 x 320 x 48 mm
Weight Approx. 2Kg
