| Camera |
| Image Sensor | 1/2.9" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.01 Lux @ F1.6 (AGC ON), B/W: 0.005 Lux @ F1.6 (AGC ON), 0 Lux with IR |
| Lens |
| Focal Length | 2.8 mm, 4 mm |
| Aperture / FOV | F1.6; 2.8 mm: H 91°, V 49°, D 108°; 4 mm: H 74°, V 40°, D 87° |
| Illuminator |
| Supplement Light Type | IR (EXIR 2.0) |
| IR Range | Up to 30 m |
| IR Wavelength | 850 nm |
| PTZ |
| Pan Range / Speed | 0° to 345°, up to 25°/s |
| Tilt Range / Speed | 0° to 80°, up to 20°/s |
| Video |
| Main Stream | 50 Hz: 20 fps (1440p, 1080p, 720p); 60 Hz: same |
| Sub-Stream | 50 Hz: 25 fps (720p, 768×432, 512×288); 60 Hz: 30 fps |
| Video Compression | Main/Sub: H.265, H.264 |
| Bit Rate | 256 kbps to 2 Mbps |
| Audio |
| Audio Compression | G.711, AAC-LC |
| Audio Bit Rate | 64 kbps (G.711ulaw/alaw); 16-64 kbps (AAC-LC) |
| Sampling Rate | 8 kHz, 16 kHz |
| Noise Filtering | Yes |
| Network |
| Protocols & API | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS; ONVIF, SDK |
| Client Support | iVMS-4200, HiLookVision, Hik-Partner-Pro |
| Wireless (Wi-Fi) |
| Encryption | WPA-PSK / WPA2-PSK |
| Protocols & Range | IEEE 802.11b/g/n, 20 MHz, up to 150 Mbps, range up to 50 m |
| Interface |
| Ethernet | 1 × RJ45 10/100 Mbps self-adaptive |
| Storage | Built-in microSD slot, up to 512 GB |
| Audio Interface | Built-in microphone & speaker |
| Event & Analytics |
| Detection | Motion detection with human/vehicle classification |
| Auto-tracking Lite | Yes |
| Deep Learning | Perimeter protection: line crossing, intrusion, region entrance/exiting |
| General |
| Power | 12 V DC ±10 %, 1 A, max. 10 W |
| Dimensions (W×D×H) | 163.9 × 185.8 × 131.9 mm |
| Weight | approx. 565 g (camera); approx. 1020 g (with package) |
| Operating Conditions | -30 °C to +50 °C; humidity ≤ 95% non-condensing |
| Material / Protection | Plastic / IP66 |
